High Accuracy Level Inclinometer Sensor, Boom Lift Angle Sensor,
High Response Frequency Angle Control Sensor
HCA520T is a high accuracy dual axis inclinometer with analog
voltage output,small measuring range and the highest precision up
to 0.003 °, it is one of the few high-precision inclinometers in
mainland. It is mainly used to measure the inclination of the
object with respect to the horizontal plane , built-in micro solid
pendulum ,by measuring the static gravity field changes then
convert into inclination change, the changes in mode output voltage
(0-5V).The internal use high-resolution differential
digital-to-analog converter, by the internal MCU system secondary
linearity and temperature correction, the customer no need to do a
secondary linearity correction, meanwhile also reducing the error
caused by environmental changes on the accuracy of the product.
This product uses non-contact measurement principle, can real-time
output current posture inclination,Simple to use, and no need to
retrieve the relative changed surface to install.Latest MEMS higher
technology production, high-precision, small size, strong
resistance to external electromagnetic interference ability, the
ability to withstand shock and vibration. It is the ideal choice
for industrial equipment, platform measuring attitude!
Features:
Dual-Axis InclinometerMeasuring Range :±1~±90° optional
Accuracyrefer to the technical dataWide voltage input: 9~36V
Wide temperature working: -40~+85°CResolution: 0.001°
Shenzhen RION, as a positon sensor manufacturer and solution
expert, attaches much importance to products reseach and develop
which spend over 20% of annual profit. We have the most R&D
personnel and best technology comparing with our peer to raise our
up on the high level of sensor field. And we orientate ourself to
market tightly and engage ourself into providing the most
considerate and professional solution and service to customers.
RION introduce advanced equipment, such as TEMP&HUMI chamber,
salt spray corrosion test chamber, high precision automatic
turntable, high precision marble checking platform, digital
thermostat drying oven, electrostatic discharge tester and 360
degree mechanical turntable etc, and set up Environmental Testing
Laboratory, Product Aging Chamber, 2D&3D Posture Calibration
Room and Shake&Impact Test Room for R&D and factory test.
Beside owning excellent hardware, RION also developed 15 sets of
software independently and keep developing, including multi-sensor
monitor software, remote sensor monitor software, synchronous
dynamic l tracking 3D presentation software, tilt switch early
warning and debugging software and sensor serial port setting
presentation software etc which could apply to XP, Win7, Win8,
WinCE and Android system. RION, owning talent and diligent
personnel, advanced technology and market-orientated strategy,
engages itself in offerring you the most considerate and
professional solution and service of position sensor.
You satisfaction is our ultimate destiny.
Packaging & Shipping
Packaging: carton with sponge
We will ship your order within 7 business days after we receive the
full payment.
If you choose ship by DHL/UPS/FEDEX/TNT,it will take 3-5 work days;
If you choose EMS ,it will take 5-7 work days.
Our Services
One year warranty is provided, during that period, we exchange and
fix the malfunction item forfree, and still we take care of
products for its lifetime.
we are position sensor solution expert, full service and support
before, in the middle of and after sales would be provided.
FAQ
We accept the payment by Escrow/Alipay,including Paypal,Credit Card
and T/T, WU.
Shenzhen Rion Technology Co., Limited(RION for short) is a
high-tech company specialized in design and manufacturing MEMS
inclinometer, 3D compass. RION has excellent developing team both
in software and hardware. In hardware, RION has the ability of
manufacture and test advanced inertial navigation and integrated
navigation system by equipment such as marble test platform,
high-low temperature chamber, super low temperature chamber,
single/triple axis turntable, several high precise automatic
indexing table, impact-vibration table, 3 axis non-magnetic
calibration bench, special vehicle carried dynamic test device and
so on. In software, our engineers are composed mainly by
professional postgraduates, doctors. we develop the inclinometer,
3D anti-magnet compass etc in China. RION’s business covers the
newest technology, tech-equipment and aerospace equipment, new
energy, IOT, energy saving and so on. RION’s products are the core
parts of automation, intelligence, informationization,
digitalization with wide application in engineering machinery,
intelligent robot, oil drilling, coal mining, technology equipment,
marine surveys, high precise mapping, new energy and so on.
RION is also honored by ISO9001 , 11 software copyright, many
products national expertise report, several appearance patent, 2
patent of invention, 7 self-developed core technology.
RION is a Chinese brand with vigor and passion, forging itself to
fully self-developed enterprise. Expecting promising future, RION
is growing rapidly, providing the best solution in position,
attitude and inertial navigation. RION rooted in China, covering
the globe, and devote itself to pursuit ever more precise value in
position, attitude.
