FCA716/FCA726180° INDUSTRIAL-GRADE INCLINOMETER WITH 0.01° ACCURACY
▶ APPLICATION
★ Single / dual axis inclination measurement
★ Range ±1 ~ ±180 ° optional
★ Accuracy: 0.008°
★ DC 9 ~ 36V wide voltage input
★ Wide temperature operation -40 ~ + 85 ℃
★ Resolution 0.001 °
★ IP67 protection grade
★ High vibration resistance> 100g
★ Aviation connector
▶ APPLICATION
★ Bridge and dam monitoring ★ Wind turbine wind tower tilt monitoring
★ Engineering vehicle leveling ★ Angle control of medical equipment
★ Railway gauge and gauge leveling ★ Attitude navigation of underground drilling rigs
★ Geological equipment tilt monitoring ★ Mining machinery, oil drilling equipment
★ Pitch angle measurement of directional satellite communication antennas
▶ GENERAL DESCRIPTION
FCA716/FCA726 is a small volume high-precision single / dual-axis inclinometer developed by RION Technology for industrial field control. It adopts RS485 / RS232 serial access interface. Built-in high-precision 24bit A / D differential converter, through the 5th order filtering algorithm, can measure the tilt and pitch angle of the sensor output relative to the horizontal plane.The product integrates the latest technology MEMS tilting unit, the measuring range up to ± 180 °, and the full-scale accuracy is 0.01 °, which can easily achieve dual-axis and single-axis tilt measurement.The product belongs to a real industrial grade
product, with reliable and stable performance, good scalability, and multiple output options. It
is suitable for the application of monitoring of ancient buildings, dilapidated buildings, ancient walls, etc., and large-scale high-precision measurement in industrial sites.
▶ SPECIFICATIONS
|  FCA716/FCA726
| CONDITION | PARAMETERS | UNIT |
| Measure range | | ±10 | ±30 | ±60 | ±90 | ±180 | ° |
| Measure axis | | X Y | X Y | X Y | X Y | X | Axis |
| Resolution | | 0.001 | 0.001 | 0.001 | 0.001 | 0.001 | ° |
| Measure accuracy | MAXE | Room temp. | 0.01 | 0.01 | 0.015 | 0.02 | 0.02 | ° |
| RMSE | Room temp. | 0.008 | 0.008 | 0.008 | 0.009 | 0.009 | ° |
| Zero Temp.coefficient | -40～85℃ | ±0.0005 | ±0.0005 | ±0.0005 | ±0.0005 | ±0.0005 | °/℃ |
| Sensitivity Temp-coefficient | -40～85℃ | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | %/℃ |
| Power on time | | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | S |
| Response frequency | 20Hz |
| Interface | TTL / RS232 / RS485 optional |
| Communication protocol | RION 68 protocol / MODBUS RTU protocol optional |
| EMC | According to EN61000 and GBT17626 |
| MTBF | ≥98000 hours/times |
| Insulation Resistance | ≥100MΩ |
| Shockproof | 100g@11ms,3 Axial Direction (Half Sinusoid) |
| Anti-vibration | 10grms,10～1000Hz |
| Protection grade | IP67 |
| Cables | Standard configuration 2m, M12 Aviation plug with PVC shielded cable, cable weight ≤120g |
| Weight | ≤150g( without cable ) |
▶ ELECTRONIC CHARACTERISTICS
|  PARAMETERS
| CONDITION | MIN | STANDARD | MAX | UNIT |
| Power supply | Standard | 9 | 12 | 24 | 36 | V |
| Working current | No load | | 21 | 12 | | mA |
| Working temperature | | -40 | | +85 | ℃ |
| Store temperature | | -40 | | +85 | ℃ |
