High Performance Digital Output Angular rate Sensor for Farming Machinery MEMS Angle rate Sensor

General Description

This product is specifically used for robotic cars, vehicle azimuth orientation, and other related applications of AGV., instead of the traditional robot vehicle magnetic bar guide shortcomings, no need at the site layout of magnetic stripe, is the necessary navigation components for the next generation of robot vehicle automatic tracing and driving.

Main Features

● Azimuth angle output ●Strong vibration resistance ●Light weight

●Long life,strong stability ●Cost-effective ●All solid state

●Compact & light design ●RS232/RS485 output optional ●DC5V power supply

Title goes here.

●AGV truck

●Platform stability

● Auto safety system

●3D virtual reality
●Industrial control

●Robot

●Car Navigation
●Turck-mounted satellite antenna equipment

Detailed Data

TL720D
Mesuring range	Azimuth Angle (±180)
Acquisition bandwidth (Hz)	>100
Resolution(°)	0.02
Azimuth accuracy (°/min)	<0.2
Nonlinear	0.3% of FS
Max angle rate (°/s)	≥150
Accelerometer range (g)	±4
Acceleroemter resultuion(g)	0.005
Acceleroemter accuracy(mg)	10
Starting time(s)	5(Static)
Input Voltage(V)	5V
Current (mA)	40(5V)
Working Temp.(℃)	-40 ~ +80
Storage Temp(℃)	-40 ~ +85
Vibration(g)	5g~10g
Impact(g)	200g pk,2ms,½sine
Working life	10 years
Output rate	5Hz,15Hz,25Hz,50Hz,100Hz can set
Output signal	RS232 or RS485
MTBF	≥50000 hours /times
Insulation resistance	≥100 Megohm
Protecting	IP67
Weight	152g(matched standard cable)

Ordering information

TL720D-232	RS232 output mode(RION protocol)
TL720D-485	RS485 output mode (RION protocol)
TL720D-232-MB	RS232 output mode (MODBUS-RTU protocol)
TL720D-485-MB	RS485 output mode (MODBUS-RTU protocol)

TL720D Measuring direction
Ordering information:
TL720D-232	RS232 output mode(RION protocol)
TL720D-485	RS485 output mode (RION protocol)
TL720D-232-MB	RS232 output mode (MODBUS-RTU protocol)
TL720D-485-MB	RS485 output mode (MODBUS-RTU protocol)

Dimension

Notice.

1.The angular gyro sensor should be mounted in the center position of the measured object , in order to reduce the influence of linear acceleration on the measurement accuracy. See below diagram as ref.

2. The installation of the instrument should be kept parallel to the surface of the measured object, and reduce the influence of the dynamic and acceleration on the angle meter. Incorrect installation will lead to measurement errors, with particular attention to "surface" and" line "

1)The mounting surface of the instrument fixing must be close, smooth and stable with the measured surface. If the mounting surface is not smooth, the angle error of angle measurement can be caused easily. See figure Pic.AB

2)The axis of the instrument must be parallel to the axis of measurement, and the two axis should not be included angle as far as possible , see figure Pic.CD

3. Do not shake violently during the use of the product, avoid violent vibration, away from the vibration source (if you can not avoid please install the shock absorber), so as not to affect the product measurement accuracy;

4. Try to avoid a sharp acceleration, arrest, sharp turn angular velocity greater than 300 DEG /s movement during use, so as not to affect the measurement precision of products.
