    HCA726S Good Temperature Drift High accuracy 2 axis Inclinometer Sensor For Solar Tracking

    Ask Lasest Price
    Brand Name : RION
    Model Number : HCA726S
    Certification : CE, ROHS
    Price : $260.00/Pieces
    Payment Terms : T/T, Paypal
    Supply Ability : 500/month
    Delivery Time : 7 days for samples
    • Product Details
    • Company Profile

    HCA726S Good Temperature Drift High accuracy 2 axis Inclinometer Sensor For Solar Tracking

    HCA726S Good Temperature Drift High accuracy 2 axis Inclinometer Sensor For Solar Tracking


    FEATURES

    ★ Single / dual axis inclination measurement

    ★ Range ±1 ~ ±180 ° optional

    ★ Accuracy: Refer to data table

    ★ DC 9 ~ 36V wide voltage input

    ★ Wide temperature operation -40 ~ + 85 ℃

    ★ Resolution 0.001 °

    ★ IP67 protection grade

    ★ High vibration resistance> 100g

    ★ Direct lead interface


    APPLICATION

    ★ Monitoring of ancient buildings and dilapidated buildings

    ★ Monitoring of bridges and large lands

    ★ Leveling of construction vehicles

    ★ Mining machinery, oil drilling equipment
    ★ Medical equipment angle control

    ★ Railway gauge ruler and gauge leveling

    ★ Underground drilling rig attitude navigation

    ★ Geological equipment tilt monitoring

    ★ Elevation angle measurement of directional satellite communication antenna

    Specification
    HCA726S Good Temperature Drift High accuracy 2 axis Inclinometer Sensor For Solar TrackingHCA716/HCA726CONDITIONPARAMETERSUNIT
    Measure range±10±30±60±90±180°
    Measure axisX YX YX YX YXaxis
    Resolution0.0010.0010.0010.0010.001°
    Measure accuracyMAXERoom temp.0.0080.010.010.020.02°
    RMSERoom temp.0.0040.0050.0050.0060.006°
    Zero Temp.coefficient-40~85℃±0.0005±0.0005±0.0005±0.0005±0.0005°/℃
    Sensitivity temp-coeffi-40~85℃≤0.01≤0.01≤0.01≤0.01≤0.01%/℃
    Power on time0.50.50.50.50.5S
    Response frequency20HZ
    InterfaceTTL / RS232 / RS485 optional
    Communication protocolRION 68 protocol / MODBUS RTU protocol optional
    EMCAccording to EN61000 and GBT17626
    MTBF≥98000 hours/times
    Insulation Resistance≥100MΩ
    Shockproof100g@11ms,3 Axial Direction (Half Sinusoid)
    Anti-vibration10grms,10~1000Hz
    Protection gradeIP67
    CablesStandard configuration: 1m length, wear-resistant,oil-proof, wide temperature, shielded cable4*0.2mm2
    Weight≤150g (including 1 meter cable)
