    PCA826 OEM Tilt Vibration Displacement Sensor For Wind Turbine

    Ask Lasest Price
    Brand Name : RION
    Model Number : PCA826
    Certification : CE, ISO
    Price : $703.00/Pieces 1-9 Pieces
    Payment Terms : T/T, Paypal
    Supply Ability : 500/month
    Delivery Time : 7 days for samples
    • Product Details
    • Company Profile

    PCA826 OEM Tilt Vibration Displacement Sensor For Wind Turbine

    Tilt Angle Measure Vibration Test Displacement Sensor for Wind Turbines


    PCA826T is a high-performance product developed by Rion Technology specially for the high-precision inclination measurement. Before leaving the factory, all products would have full temperature range calibration and compensation, and a two-week long-term stability test ensures compatibility under different working conditions and maintains the best performance indicators during the long-term test cycle. The product integrates the FFT function, which can measure the vibration of 0.5~8HZ, and estimate the vibration frequency of the object to obtain the maximum speed and maximum displacement of the object vibration. Integrate two kinds of output protocols including the industrial standard MODBUS protocol, the supporting computer analysis software can display and record the measurement data in real time. The output interface could be RS485 or RS422. The non-contact installation makes PCA826T easy to install or integrate. Strong resistance to external electromagnetic interference, strong anti-shock and vibration ability, widely used in satellite communication system processing , radar antenna vehicles, etc.

    ▶ MAIN FEATURES

    ★ Biaxial tilt angle measurement

    ★ Range ±1~±60° optional

    ★ Horizontal/vertical optional

    ★ DC 9~36V wide voltage input

    ★ Wide temperature operation -40~+85℃

    ★ Resolution 0.0005°

    ★ IP67 protection grade

    ★ Size: L82×W70×H42mm

    ★ Output mode RS485, RS422 optional


    APPLICATION


    ★ Wind power monitoring

    ★ Bridge and Dam monitoring

    ★ Ancient building monitoring

    ★ High-speed rail track monitoring

    ★ Ground satellite communication vehicles

    ★ Railway gauge ruler and gauge leveling

    ★ Satellite communication vehicle

    ★ Geological equipment tilt monitoring

    ★ Engineering vehicle leveling

    Specification
    PCA826T CONDITIONPARAMETERSUNIT
    Measure range±5±10±30±60°
    Measure axisXYXYXYXY
    Resolution0.00050.00050.00050.0005°
    Measure accuracy@25℃0.0010.0020.0030.005°
    Long-term stability0.020.020.030.04°
    Zero temp coefficient-40~85℃0.00020.00020.00020.0002°/℃
    Sensitivity temp coefficient-40~85℃≤50≤50≤50≤50ppm/℃
    Power on time<0.4<0.4<0.4<0.4S
    Response frequency0.040.040.040.04S
    Output rate5Hz,10Hz,25Hz,35Hz,50Hz,100Hz. Can be set
    Ouput signalRS485/RS422 optional
    EMCAccording to EN61000 and GBT17626
    MTBF≥50000 hour/time
    Insulation Resistance≥100 MΩ
    Shockproof100g@11ms,3 Axial Direction (Half Sinusoid)
    Anti-vibration10grms,10~1000Hz
    Protection gradeIP67
    CablesStandard configuration 1 meter, wear-resistant, wide temperature, shielded cable, mm aviation connector
    Weight385g (exclude cable)
    CertificationsPCA826 OEM Tilt Vibration Displacement Sensor For Wind Turbine

    RION Technology Co., Ltd. is located in a fantastic city - Shenzhen. Our company is a high technology company that integrates research, development, production and sale, and is mainly engaged in the sale of inclinometer sensors, digital compasses, gyro sensor, acceleration sensors and so on. These products are widely used in many industrial control fields, such as automobiles, ships, airplanes, railways, medical facilities, dam safety monitoring, oil drilling, coal mining and ocean surveying. Our company has established good business relationships with many international famous companies.
