    Magnetic Base Digital Angle Finder Box Single Axis RS485 180deg Rion Inclinometer

    Ask Lasest Price
    Brand Name : RION
    Model Number : DMI410/420-90
    Supply Ability : 30000 Set/Sets per Month
    Price : $248.00/Sets
    Certification : CE
    Payment Terms : T/T, Paypal
    Delivery Time : 5-10 work days
    • Product Details
    • Company Profile

    Magnetic Base Digital Angle Finder Box Single Axis RS485 180deg Rion Inclinometer

    DMI410 single-axis 180deg measurement range Digital Angle Finder Box Magnetic Base 2 Axis Digital Inclinometer

    PRODUCT DESCRIPTION

    DMI410&DMI420 is a digital display inclinometer which took RION company three years to develop professional for various industry angle control and measuring.The core of this product is using the micro-mechanical control principle, dual-core measurement unit, can use the Y-axis to compensate X-axis during the measurement process,a and then to use RION patent interleaved and temperature compensation model algorithm to play absolute operation advantages of the micro-mechanical electronic principles,to ensure that the instruments measurement with the long-term stability and repeatability. MI410 single axis ±180° measurement, DMI420 dual axis ±90° measurement,resolution 0.01 °,accuracy <0.05 degree full-scale,fast response, stable data, products specially designed for the sides and bottom with magnetic adsorption installation, both sides of the benchmark can be measured and using normally,very convenient to use,This product series has strong scalability, convenient & practical application and industrial reliability, has absolute cost advantage and has an absolute competitive advantage in the international market !


    KEY FEATURES

    ★ Auto-angle interleaved compensation function ★ Auto temperature drift compensation

    ★ User can calibrate by himself ★ Built-in recharge industry battaries

    ★ Night vision fours colors screen ★ IP54 protection class

    ★ Angle/length dual unit switch ★ 100g High anti-impact


    APPLICATION

    ★ Building construction ★ Automobile four-wheel testing ★ Road slope ★ Machinery installation ★ Piping installation ★ Industrial platform

    ★ Turntable testing ★ Cloud deck angle detection ★ Production jig


    TECHNICAL DATA

    PARAMETERSMagnetic Base Digital Angle Finder Box Single Axis RS485 180deg Rion InclinometerDMI410 DMI420
    Angle measure range±180 °±90 °
    Length measure range0~±999.9mm/m0~±999.9mm/m
    Measure axisSingle axisDual axis
    Angle measure accuracy0.05 °(full range)0.05 °(full range)
    Angle measure resolution0.01°0.01°
    Length measure accuracy0.9mm/m(full range)0.17mm/m(full range)
    Length measure resolution0.17mm/m0.1mm/m
    LCD visible area sizeL40*W32mm
    Working temperature-10℃~ +70℃
    Working humidity85℃
    Power supply3.7V Charging Lithium battery
    Ideal charging time3h
    Battery continuous working time8h(±0.5)
    Data output signalStandard 5Pin USB connector
    Anti-vibration10g@11ms,3 Axial Direction (Half Sinusoid)
    Impact resistance10grms,10~100Hz
    Weight125g
    Waterproof levelIP54
    MaterialMetal aluminum
    SizeL83*W53*H19.2mm

    ORDER INFORMATION

    Item No.Order description
    DMI410Standard single axis digital display inclinometer /measure range ±180°(length 0~±999.9mm/m)
    DMI420Standard Dual axis digital display inclinometer /measure range ±90°(length 0~±999.9mm/m)


    Product Functions:

    Magnetic Base Digital Angle Finder Box Single Axis RS485 180deg Rion Inclinometer
