    TL740D CAN2.0A 3D Digital Compass TL740D 3 Axis Accelerometer Gyroscope

    Ask Lasest Price
    Model Number : TL740D-CAN
    Brand Name : Rion
    Supply Ability : 3000 Piece/Pieces per Month
    Price : $224/Pieces
    Certification : CE, ISO
    Payment Terms : T/T, Paypal
    Delivery Time : 7 days for samples
    • Product Details
    • Company Profile

    TL740D CAN2.0A 3D Digital Compass TL740D 3 Axis Accelerometer Gyroscope

    TL740D CAN2.0A 3D Digital Compass TL740D 3 Axis Accelerometer Gyroscope

    Product Overviews

    ▶ KEY FEATURES

    ★ Azimuth angle output ★ Strong vibration resistance ★ Light weight

    ★ Long life,strong stability ★ Cost-effective ★ All solid state

    ★ Compact & light design ★ CAN2.0A/CAN2.0B output optional ★ DC9~36V power supply


    ▶ APPLICATION

    ★ AGV truck ★ Car Navigation ★ 3D virtual reality

    ★ Platform stability ★ Auto safety system ★ Robot

    ★ Turck-mounted satellite antenna equipment ★ Industrial control


    ▶ GENERAL DESCRIPTION

    TL740D is RION-TECH newly developed horizontal azimuth angular gyro sensor based on latest MEMS inertial measurement platform , by means of the dynamic attitude algorithm for the angular velocity of gyroscope ,it can simultaneously output carrier’s azimuth angle .The product inernal integrated RION-TECH Patent Inertial navigation algorithm, through the model of attitude angle data fusion , can solve the gyro short time drift problem as much as possible .

    This product is specially used for robot car, AGV vehicle azimuth orientation, attitude control and other related applications , instead of the traditional robot vehicle magnetic bar guide shortcomings, no need at the site layout of magnetic stripe, is the necessary navigation components for the next generation of robot vehicle automatic tracing and driving.


    TL740DPARAMETERS
    Mesure rangeAzimuth Angle (±180°)
    Acquisition bandwidth>100Hz
    Resolution0.01°
    Azimuth accuracy<0.1°/min
    positional accuracy<2mm/m (converted from angle accuracy)
    Nonlinear0.1% of FS
    Max angle rate150°/s
    Acceleration range±4g
    Acceleration resolution0.001g
    Acceleration accuracy5mg
    Starting time5s(Static)
    Input Voltage+9V~36V
    Current60mA(12V)
    Working Temp.-40 ~ +85℃
    Storage Temp.-40 ~ +85℃
    Vibration5g~10g
    Impact200g pk,2ms,½sine
    Working life10 years
    Output rate1Hz~100Hz can set
    Output signalCAN2.0A / CAN2.0B
    MTBF≥98000 hours /times
    Insulation resistance≥100 Megohm
    Impact resistance100g@11ms / 3 Axial Direction (Half Sinusoid)
    Anti-vibration10grms / 10~1000Hz
    ProtectingIP67
    Weight130g(Without cable)
