Waterproof Dual Axis Tilt Sensor Inclinometer Analog Voltage Signal
▶ TECHNICAL DATA
| HCA510&520T | CONDITION | PARAMTERS | UNIT |
| Measure range | | ±10 | ±30 | ±60 | ° |
| Measure axis | | X | X | X | |
| Zero output | 0° output | 2.5 | 2.5 | 2.5 | V |
| Resolution | | 0.001 | 0.001 | 0.001 | ° |
| Measure accuracy | @25℃ | 0.005 | 0.01 | 0.02 | ° |
| Long term stability | | 0.01 | 0.02 | 0.05 | ° |
| Zero Temp. coefficient | -40～85℃ | ±0.002 | ±0.002 | ±0.002 | °/℃ |
| Sensitivity temp. coefficient | -40～85℃ | ≤100 | ≤100 | ≤100 | ppm/℃ |
| Power on time | | 0.5 | 0.5 | 0.5 | S |
| Response time | | 0.02 | 0.02 | 0.02 | s |
| Response frequency | | 1～20 | 1～20 | 1～20 | Hz |
| EMC | According to EN61000 and GBT17626 |
| MTBF | ≥50000 hours/times |
| Insulation Resistance | ≥100MΩ |
| Shockproof | 100g@11ms,3 Axial Direction (Half Sinusoid) |
| Anti-vibration | 10grms,10～1000Hz |
| Protection glass | IP67 |
| Cables | Standard configuration: 1m length, wear-resistant, wide
temperature, shielded cable 5*0.4mm2 aviation connector |
| Weight | 190g(without cable ) |
▶ GENERAL DESCRIPTION
HCA510T & HCA520T is a high-precision analog voltage output single
/ dual axis inclination sensor. The highest precision in a small
range can reach 0.003 °. It is one of the few high-precision
inclinometers in China. Its function is mainly used to measure the
inclination of the object based on horizontal plane.
Built-in micro solid pendulum ,by measuring the static gravity
field changes then convert into inclination change,the changes in
mode output voltage (0-5V).The internal use high-resolution
differential digital-to-analog converter, by the internal MCU
system secondary linearity and temperature correction, the customer
no need to do a secondary linearity correction, meanwhile also
reducing the error caused by environmental changes on the accuracy
of the product.
This product uses non-contact measurement principle, can real-time
output current posture inclination,Simple to use, and no need to
retrieve the relative changed surface to install.Latest MEMS higher
technology production, high-precision, small size, strong
resistance to external electromagnetic interference ability, the
ability to withstand shock and vibration. It is the ideal choice
for industrial equipment, platform measuring attitude!
▶ FEATURES
★ Single / dual axis inclination measurement
★ Range ± 1 ～ ± 60 ° optional
★ Accuracy: Refer to technical data
★ Wide voltage input 9 ～ 36V
★ Output mode 0 ～ 5V
★ Wide temperature operation -40 ～ + 85 ℃
★ IP67 protection
★ High vibration resistance> 2000g
★ High resolution 0.001 °
★ Small size L90mm × W50mm × H34mm (customizable)
▶ APPLICATION
★ Equipment vehicle leveling
★ Bridge and Dam monitoring
★ High-altitude platform safety protection
★ Angle control of medical equipment
★ Attitude navigation of underground drilling rig
★ Leveling of railway gauge and gauge
★ Direction measurement based on tilt angle
★ Tilt monitoring of geological equipment
★ Pitch angle measurement of directional satellite communication
antenna
★ Mining machinery, oil drilling equipment
★ Equipment level control
★ Alignment control , curve control
