RION DMI810 High Reliable Touch Screen Digital Inclinometer

http://en.rion-tech.net/products_detail/productId=65.html

▶ GENERAL DESCRIPTION

DMI810&DMI820 is a digital display inclinometer which took RION company three years to develop professional for various industry angle controling and measuring.The core of this product is using the micro-mechanical control principle, dual-core measurement unit, can use the Y-axis to compensate X-axis during the measurement process,and then to use RION patent interleaved and temperature compensation model algorithm to play absolute operation advantages of the micro-mechanical electronic principles,to ensure that the instruments measurement with the long-term stability and repeatability. Single and double axis measurement, measurement range ±30° measurement, resolution 0.001°, highest accuracy <0.005° full value,fast response, stable data, products specially designed for the sides and bottom with magnetic adsorption installation, both sides of the benchmark can be measured and using normally,very convenient to use, DMI810 series has strong scalability, convenient & practical application and industrial reliability, has absolute cost advantage and has an absolute competitive advantage in the international market !

▶ FEATURES

★ Best accuracy:<0.005° ★ Repeatability:0.003°

★ Angle resolution:0.001° ★ Maximum measure range:±30°

★ User can set the alarm value by himself ★ Data store function

★ Absolute/Relative measurement can switch ★ Both sides and bottom can measure

★ Double benchmark strong magnet installation ★ Working Temperature : -10°～ +70℃

★ Auto-angle interleaved compensation function ★ Auto temperature drift compensation

★ User can calibrate ZERO by himself ★ Built-in rechargable industry batteries

★ Night vision fours colors screen ★ IP54 protection class

★ °/mm/m Dual units switch function ★ Filter frequency optional

★ Three kinds of measurement mode selectable (radian, angle, mm)

▶ APPLICATION

★ Building construction ★ Automobile four-wheel testing ★ Road slope

★ Machinery installation ★ Piping installation ★ Industrial platform
★ Turntable testing ★ Pan unit angle detection ★ Production jig

Shenzhen Rion Technology Co., Limited(RION for short) is a high-tech company specialized in design and manufacturing MEMS inclinometer, 3D compass. RION has excellent developing team both in software and hardware. In hardware, RION has the ability of manufacture and test advanced inertial navigation and integrated navigation system by equipment such as marble test platform, high-low temperature chamber, super low temperature chamber, single/triple axis turntable, several high precise automatic indexing table, impact-vibration table, 3 axis non-magnetic calibration bench, special vehicle carried dynamic test device and so on. In software, our engineers are composed mainly by professional postgraduates, doctors. we develop the inclinometer, 3D anti-magnet compass etc in China. RION’s business covers the newest technology, tech-equipment and aerospace equipment, new energy, IOT, energy saving and so on. RION’s products are the core parts of automation, intelligence, informationization, digitalization with wide application in engineering machinery, intelligent robot, oil drilling, coal mining, technology equipment, marine surveys, high precise mapping, new energy and so on.

RION is also honored by ISO9001 , 11 software copyright, many products national expertise report, several appearance patent, 2 patent of invention, 7 self-developed core technology.

RION is a Chinese brand with vigor and passion, forging itself to fully self-developed enterprise. Expecting promising future, RION is growing rapidly, providing the best solution in position, attitude and inertial navigation. RION rooted in China, covering the globe, and devote itself to pursuit ever more precise value in position, attitude.
