    HDA436T CAN2.0 Dynamic Attitude Sensor MEMS Gyro Sensor Angle Measuring

    Ask Lasest Price
    Model Number : HDA436T-232-68
    Brand Name : RION
    Price : $161.00/Pieces
    Certification : CE, ISO
    Payment Terms : T/T, Paypal
    Supply Ability : 5000/month
    Delivery Time : 7 days for samples
    • Product Details
    • Company Profile

    HDA436T CAN2.0 Dynamic Attitude Sensor MEMS Gyro Sensor Angle Measuring

    New Generation CAN2.0 Dynamic Sensor for Excavators Angle Measuring
    ▶ PRODUCT DESCRIPTION

    HDA436T CAN2.0 Dynamic Attitude Sensor MEMS Gyro Sensor Angle Measuring

    HDA436T,A new generation of digital MEMS dynamic tilt sensor launched by RION Technology. It can measure the attitude parameters (roll, pitch, and azimuth) of a moving carrier, and suitable for tilt angle measurement under motion or vibration.

    ▶ PRODUCT FEATURES

    ★ Range (Roll angle ± 180 °, pitch angle ± 90 °, azimuth angle ± 180 °)
    ★ Dynamic accuracy: ± 0.1 °
    ★ DC 9 ~ 36V wide voltage input
    ★ Wide temperature operation -40 ~ + 85 ℃ ★ Resolution 0.01 °
    ★ IP67 protection level ★ High anti-vibration performance> 2000g
    ★ Size: L72XC47X H22.5mm

    ▶ APPLICATION

    ★ Satellite search satellites
    ★ Railway locomotive monitoring ★ Oil drilling equipment
    ★ Shield pipe jacking application ★ Radar vehicle platform detection

    HDA536T
    Condition
    Index
    Measuring
    /
    Roll ± 180 °, pitch ± 90 °, azimuth ± 180 ° (initial value at power-down is 0 °)
    Measuring axis
    /
    X axis / Y axis / Z axis
    Resolution
    0.01°
    Static accuracy
    @25℃
    ± 0.05°
    Dynamic accuracy
    @25℃
    ± 0.1°
    Bias Instability (Allan)
    8°/h
    Zero point temp. coefficient
    -40~85°
    ±0.01°/℃
    Sensitivity temp. coefficient
    -40~85°
    ≤100ppm/℃
    Power-on startup time
    1S
    Response time
    0.01S
    Output signal
    RS485/RS232/TTL
    Electromagnetic compatibility
    According to EN61000 and GBT17626
    MTBF
    ≥ 50000 hours / time
    Insulation resistance
    ≥100 Megohm
    Impact resistance
    100g @ 11ms, Triaxial and identical (half sine wave)
    Anti- vibration
    10grms,10~1000Hz
    Protection grade
    IP67
    Cable
    2m length, wear-resistant, oil-proof, wide temperature, shielded cable 5 * 0.34mm2, wire weight 100g
    Weight
    295g (excluding cable)

    HDA436T CAN2.0 Dynamic Attitude Sensor MEMS Gyro Sensor Angle Measuring
    HDA436T CAN2.0 Dynamic Attitude Sensor MEMS Gyro Sensor Angle Measuring
    HDA436T CAN2.0 Dynamic Attitude Sensor MEMS Gyro Sensor Angle Measuring
