dual axis digital inclinometer with touch screen platform
calibration angle value display device ,industrial angle measure
▶ GENERAL DESCRIPTION
DMI810&DMI820 is a digital display inclinometer which took RION
company three years to develop professional for various industry
angle controling and measuring.The core of this product is using
the micro-mechanical control principle, dual-core measurement unit,
can use the Y-axis to compensate X-axis during the measurement
process,and then to use RION patent interleaved and temperature
compensation model algorithm to play absolute operation advantages
of the micro-mechanical electronic principles,to ensure that the
instruments measurement with the long-term stability and
repeatability. Single and double axis measurement, measurement
range ±30° measurement, resolution 0.001°, highest accuracy
<0.005° full value,fast response, stable data, products
specially designed for the sides and bottom with magnetic
adsorption installation, both sides of the benchmark can be
measured and using normally,very convenient to use, DMI810 series
has strong scalability, convenient & practical application and
industrial reliability, has absolute cost advantage and has an
absolute competitive advantage in the international market !
▶ FEATURES
★ Best accuracy:<0.005° ★ Repeatability:0.003°
★ Angle resolution:0.001° ★ Maximum measure range:±30°
★ User can set the alarm value by himself ★ Data store function
★ Absolute/Relative measurement can switch ★ Both sides and bottom
can measure
★ Double benchmark strong magnet installation ★ Working Temperature
: -10°～ +70℃
★ Auto-angle interleaved compensation function ★ Auto temperature
drift compensation
★ User can calibrate ZERO by himself ★ Built-in rechargable
industry batteries
★ Night vision fours colors screen ★ IP54 protection class
★ °/mm/m Dual units switch function ★ Filter frequency optional
★ Three kinds of measurement mode selectable (radian, angle, mm)
▶ APPLICATION
★ Building construction ★ Automobile four-wheel testing ★ Road
slope
★ Machinery installation ★ Piping installation ★ Industrial
platform
★ Turntable testing ★ Pan unit angle detection ★ Production jig
 PARAMETER | DMI810 | DMI820 | UNIT |
| Angle Measure range | ±15 ° | ±30 ° | ±15 ° | ±30 ° | ° |
| MM measure range | 267 | 577 | 267 | 577 | mm/m |
| Meausre axis | Single axis | Single axis | Single axis | Single axis | |
| Highest measurement accuracy (full range) | <0.005 | <0.01 | <0.005 | <0.01 | °(RMS) |
| Angle Measure resolution | 0.001 | 0.001 | 0.001 | 0.001 | ° |
| Repeatability | 0.003 | 0.003 | 0.003 | 0.003 | ° |
| MM measure accuracy | 0.1 | 0.2 | 0.1 | 0.2 | mm/m |
| Three measurement mode selectable | ①Angle ②degree, minute, second ③mm/m three modes can be set | / |
| MM measure res | 0.02 | mm/m |
| LCD | 64 true colors night vision display screen | / |
| LCD visible area size | L57.6*W43.2 | mm |
| Working temperature | -10°~ +70℃ | ℃ |
| Working humidity | 85 | %RH |
| Power supply | 3.7V Charging Lithium battery | V |
| Ideal charging time | 5 | h |
| Battery sustainable charging times | 11 | h |
| Equipped with PC software | VC software | / |
| Data output signal | USB1.1 (Virtual Serial Device) | / |
| Connect plug in | Standard USB connector, rechargeable | / |
| Shock resistance | 10g@11ms,3 Axial Direction (Half Sinusoid) | g |
| Shock impact | 10grms,10~100Hz | g |
| Waterproof grade | IP54 | / |
| Material | Aluminum alloy Anodizing | / |
| Size | L107*W75*H27.1 | mm |
| Weight | 300 | g |
FAQ
How long is the delivery time of the products?
A: Usually we have stock for every type of products, if the product
that you selected we have in stock, then we only need to re-test it
before leaving the factory, so the delivery time is around 2~4 days; if we don’t have them in stock, then we need to arrange the
production, the delivery time will be around 2 weeks. For the
customer-oriented design products, our engineers will give the
approximate delivery time according to the technical requirements.
Q: How about the payment conditions?
A: we accept 40% prepayment in advance, and the balance 60% payment before the delivery. For the customer-oriented design
product, the payment will be discussed together.
Q: How will we do if the product has the quality problem?
A: Our products have passed very strict tests before delivery, so
it is very low probability to have quality problem. If our products
have quality problem (not caused by man-made factors) in the
warranty period, our factory will arrange the free repair. If the
product can’t repair well, we will arrange to provide a new one. If
the product is out of warranty time, we will provide the repair
only charging the material cost.
