SCA116T&SCA126T Dual Axis Inclinometer w/ RS232/RS485 Output,
IP67 Protection
▶ FEATURES
★ Single / dual axis inclination measurement
★ Range ±1～±90 ° optional
★ Two communication protocols are optional
★ DC 9～36V wide voltage input
★ Wide temperature operation -40～+ 85 ℃
★ Resolution 0.01 °
★ IP67 protection level
★ High anti-vibration performance> 2000g
★ Direct lead interface
▶ APPLICATION
★ Satellite antenna searching
★ Railway locomotive monitoring
★ Oil drilling equipment
★ Radar vehicle platform detection
★ Attitude navigation of underground drilling rig
★ Geological equipment tilt monitoring
★ Shield jacking application
★ Ship navigation attitude measurement
★ Various construction machinery inclination measurement
★ Direction measurement based on the inclination angle
★ Attitude detection of the satellite communication vehicle
▶ PRODUCTION
SCA116T & SCA126T is the MODBUS output inclination sensor launched
by RION Technology for industrial field control. It uses RS485
hardware differential bus to transmit data. Built-in high-precision
16bit A / D differential converter, through the 5th order filtering
algorithm, can measure the tilt and pitch angle of the sensor
output relative to the horizontal plane. built-in high-precision
digital temperature sensorI, the temperature drift of the sensor
can be corrected according to the change of the built-in
temperature sensor to ensure the high repeatability of the product
in low temperature and high temperature environments. The output
response frequency standard can be up to 18Hz. If a higher response
frequency is needed, our company can customize it according to the
user. The product belongs to a real industrial grade product, with
reliable and stable performance, good scalability, and multiple
output options. Suitable for various harsh industrial control
environments.
▶ PERFORMANCE PARAMETERS
| SCA116T/126T | CONDITION | PARAMETER | UNIT |
| Measure range | | ±10 | ±30 | ±60 | ±90 | ° |
| Measure axis | | X Y | X Y | X Y | X Y | axis |
| Resolution | | 0.01 | 0.01 | 0.01 | 0.01 | ° |
| Measure accuracy | @25℃ | 0.02 | 0.03 | 0.05 | 0.06 | ° |
| Long term.stability | | 0.05 | 0.05 | 0.05 | 0.05 | ° |
| Zero Temp.coefficient | -40～85℃ | ±0.006 | ±0.006 | ±0.006 | ±0.006 | °/℃ |
| Sensitivity temp-coeffi | -40～85℃ | ≤100 | ≤100 | ≤100 | ≤100 | ppm/℃ |
| Power on time | | 0.5 | 0.5 | 0.5 | 0.5 | S |
| Response time | | 0.02 | 0.02 | 0.02 | 0.02 | s |
| Output rate | 5Hz,15Hz,35Hz,50Hz Optional |
| communication protocol | MODBUS / ROIN 68 Optional |
| EMC | According to EN61000 and GBT17626c |
| MTBF | ≥50000 hours/times |
| Insulation Resistance | ≥100MΩ |
| Shockproof | 100g@11ms,3 Axial Direction (Half Sinusoid) |
| Anti-vibration | 10grms,10～1000Hz |
| Protection grade | IP67 |
| Cables | Standard as 1-meter length, wear-resistant, oil-proof, wide
temperature, shielded cable 4 * 0.4mm2 |
| Weight | 165g(exclude cable) |
* This performance parameter only lists ± 10 °, ± 30 °, ± 60 °, ±
90 ° series as a reference, for other measurement ranges, please
refer to the most adjacent parameters.
▶ ELECTRICAL PARAMETERS
 PARAMETERS | CONDITION | MIN | TYPICAL | MAX | UNIT |
| Power supply voltage | Standard | 9 | 12,24 | 36 | V |
| Optional | | 5 | | V |
| Working current | 5V | | 42 | | mA |
| 12V | | 26 | | mA |
| 24 | | 17 | | mA |
| Working temp. | | -40 | | +85 | ℃ |
| Store temp. | | -40 | | +85 | ℃ |
