High-Precision 0.01° Dynamic Inclinometer for Accurate Measuring
and Analysis
▶ PRODUCT DESCRIPTION
HDA436T/HDA437T A new generation of digital MEMS dynamic tilt
sensor launched by RION
Technology. It can measure the attitude parameters (roll, pitch,
and azimuth) of a moving carrier, and
suitable for tilt angle measurement under motion or
vibration.HDA436T has a built-in high-precision
acceleration and gyro sensor, and integrates the Carman filter
algorithm, which can measure the
real-time motion data of the carrier under motion or vibration. The
signal output modes such as RS485 /
RS232 / TTL are optional, and the scalability is strong.
This product adopts non-contact measuring principle, which can
output the current attitude and
inclination in real time. It is simple to use and does not need to
retrieve the relative changes of the two
surfaces.Internally integrated high-precision AD and high-precision
gyro units to compensate for
non-linear, orthogonal coupling, temperature drift and centrifugal
acceleration in real time; greatly
eliminate centrifugal errors caused by motion acceleration
interference, improve product dynamic
measurement accuracy; adapt to long-term complex movements Work in
places and harsh
environments.The product is a dynamic and static dual-mode
measurement sensor with strong
resistance to external electromagnetic interference.It is suitable
for all kinds of large-scale and
high-strength shock and vibration industrial environments, and is
an ideal choice for industrial automation
control and measurement of attitude.
▶ KEY FEATURES
★ Range (Roll angle ±180°, pitch angle ±90°, azimuth angle ±180°)
★ Dynamic accuracy: ± 0.1°
★ Static accuracy: ± 0.05°
★ RS485/232/TTL output Optional
★ Wide temperature operation -40~+ 85℃
★ DC 9~6V wide voltage input
★ Resolution 0.01°
★ IP67/IP68 Protection level Optional
▶ PRODUCT APPLICATION
★ High vibration impact gravel equipment
★ Railway locomotive monitoring
★ Oil drilling equipment
★ Shield pipe jacking application
★ Shield pipe jacking application
★ Geological equipment tilt monitoring
★ Underground drilling rig attitude navigation
★ Ship navigation attitude measurement
 HDA436T | CONDITION | INDEX |
| Measure range | - | Roll ±180°, pitch ±90°, azimuth ±180° (initial value at power-down is 0°) |
| Measure axis | - | X axis / Y axis / Z axis |
| Resolution | - | 0.01° |
| Static accuracy | @25℃ | ± 0.05° |
| Dynamic accuracy(RMS) | @25℃ | ± 0.1° |
| Gyro | range | - | ±250°/s |
| Zero bias stability (10s mean) | - | 8.5°/h |
| Zero Bias Instability(allan) | - | 4.5°/h |
| Angle random walk coefficient(allan) | - | 0.25°/sqrt(h) |
| Acceleration | range | - | ±8g |
| Bias stability(10s mean) | - | 0.02mg |
| Bias instability(allan) | - | 0.005mg |
| Speed random walk coefficient(allan) | - | 0.005m/s/sqrt(h) |
| Zero point temp. coefficient | -40～85℃ | ±0.01°/℃ |
| Sensitivity temp. coefficient | -40～85℃ | ≤100ppm/℃ |
| Power-on startup time | 1S |
| Response time | 0.01S |
| Output signal | RS485/RS232/TTL |
| Electromagnetic compatibility | According to EN61000 and GBT17626 |
| MTBF | ≥ 98000 hours / time |
| Insulation resistance | ≥100 Megohm |
| Impact resistance | 100g @ 11ms,3 axial direction (half sinusoid) |
| Anti-vibration | 10grms,10～1000Hz |
| Waterproof level | standard configuration: IP67 optional configuration: IP68 or IP68 with anti-corrosion cable |
| Cable | Standard without wiring, optional 2m M12 aviation plug with PVC
unshielded cable |
| Weight | ≤165g (excluding cables) |
PARAMETER
