TL720D IMU Gyro Sensor 9 axis Output Sensor Triaxial Accelerometer Triaxial Gyro Sensor Triaxial Attitude Sensor

▶ FEATURE

★ Horizontal azimuth and attitude angle output

★ Real-time angular rate output

★ Long life and strong stability

★ Forward axis acceleration

★ Compact and lightweight design

★ DC9~36V power supply

▶APPLICATION

★ Automated agricultural machinery

★ Precision agriculture

★ Combination Harvesters

★ Farming machine

PRODUCT SPECIFICATIONS

TL720D		Parameters
Mesure range		Azimuth Angle (±180)°
Acquisition bandwidth		>100Hz
Resolution		0.01°
Azimuth accuracy		<0.1°
Nonlinear		0.1% of FS
Pitch measurement range		±90°
Pitch measurement accuracy		0.25°(1σ)
Roll measurement range		±180°
Roll measurement accuracy		0.25°(1σ)
Accelerometer	Accelerometer range	±4g
	Acceleroemter resultuion	0.001g
	Acceleroemter accurac	5mg
	Bias instability (allan)	0.05mg
	Speed random walk coefficient (allan)	0.015m/s/sqrt(h)
	Bias stability (10s average)	0.15mg
Gyro	Gyro Angular Velocity Range	±250°/s
	Bias instability (allan)	5.0°/h
	Angle random walk coefficient (allan)	0.30°/sqrt(h)
	Bias stability(10s average value)	10°/h
Starting time		AGV application: 5~6s
		AGM application: 1.5s
Input Voltage		9~36VDC / 5VDC (Optional)
Current		30mA(12V)
Working Temp.		-40℃ ~ +80℃
Storage Temp		-40℃ ~ +85℃
Vibration		5g~10g
Impact		200g pk,2ms,½sine
Working life		10 years
Output rate		5Hz~200Hz can set
Output signal		RS232 or RS485
MTBF		≥50000 hours /times
Insulation resistance		≥100 Megohm
Impact resistance		100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration		10grms,10～1000Hz
Protecting		IP67
Weight		≤135g (including 1 meter standard cable)

TL720D-C2/C3		PARAMETERS
Heading measure axis		Z axis heading angle (±180)°
Bandwidth		>100Hz
Resolution		0.01°
Heading accuracy		<0.1°/m
Position accuracy		<2mm/m (According to the angle conversion)
Nonlinear		0.1% of FS
Pitch measurement range		±90°
Pitch measurement accuracy		0.25°(1σ)
Roll measurement range		±180°
Roll measurement accuracy		0.25°(1σ)
Accelerometer	Accelerometer range	±4g
	Acceleration resolution	0.001g
	Acceleration accuracy	5mg
	Bias instability (allan)	0.05mg
	Speed random walk coefficient (allan)	0.015m/s/sqrt(h)
	Bias stability (10s average)	0.15mg
Gyro	Max Gyro Range	±250°/s
	Bias instability (allan)	5.0°/h
	Angle random walk coefficient (allan)	0.30°/sqrt(h)
	Bias stability(10s average value)	10°/h
Startup time		AGV application: 5 ~ 6s
		AGM application: 1.5s
Input voltage		9~36VDC / 5VDC(optional )
Working current		30mA(12V)
Working temp		-40℃ ~ +80℃
Storage temp		-40℃ ~ +85℃
Vibration		5g~10g
Impact		200g pk,2ms,½sine
Working life		10 years
Output rate		1Hz~100Hz can set
Output signal		CAN2.0A / CAN2.0B(optional )
MTBF		≥98000Hours/times
Insulation resistance		≥100 MΩ
Shockproof		100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration		10grms,10～1000Hz
Protection grade		IP67
Weight		≤135g (including 1 meter standard cable)
