▶ FEATURE

★ Heading Accuracy: 0.3°～0.5°

★ Roll Range:±180°

★ Tilt Resolution: 0.1°

★ Tilt Accuracy: <0.2°(Full Range)

★ Wide Temp.Range: -40℃～+85℃

★ With Hard-Soft Magnetic And Tilt Compensation

▶ APPLICATION

★ Satellite Antenna Search Satellite

★ Gps Integrated Navigation

★ Antenna Servo Control

★ Laser Range Finder

★ Map For Plotter

★ Rov Underwater Robot Navigation

★ Oceanography Measurement Instruments

★ Special Occasion Robot

▶ PRODUCT INTRODUCTION

HCM600/HCM605 is a dynamic and high-precision 3 axis electronic compass, which integrates three-axis accelerometer, three-axis gyroscope and three-axis magnetic sensor. User can order complete product with housing (up to IP67 waterproof level) or compass module.

HCM600B/HCM605B parameters
heading	Heading accuracy	0.5° tilt<10°
	Resolution	0.1°
Tilt parameters	Pitch accuracy	0.1°<15°(measure range)
		0.1°<30°(measure range)
		0.1°<60°(measure range)
		0.2°<85°(measure range)
	Pitch range	±85°
	Roll accuracy	0.1°<15°(measure range)
		0.1°<30°(measure range)
		0.1°<60°(measure range)
		0.2°<180°(measure range)
	Roll range	±180°
	Resolution	0.1°
Calibration	Hard iron calibration	Yes
	Soft iron calibration	Yes
	Magnetic interference calibration	Rotate 360deg horizontally; vertical rotation(option)
Physical feature	Size	L111.5×W19.5×H19.5mm
	Weight	≤85g(exclude cable)
	RS232/RS485/TTL	5PIN quick plug connector
interface	Start delay	<50ms
	Max output speed	20Hz/s
	Communication speed	2400 to 115200baud (default 9600)
	Output format	Binary High-performance Protocol
Power	Power voltage	(default) DC+5V
	Current(max)	30mA
	Ideal mode	26mA
	Hibernate mode	TBD
Environment	Operating range	-40℃～+85℃
	Storage temperature	-40℃～+85℃
	Vibration resistance	100g
	Protection	IP67
Electromagnetic compatibility	According to EN61000 and GBT17626
MTBF	≥40000 hours/time
Insulation resistance	≥100mego-ohm
Impact resistant	100g11ms, 3 Axial Direction (Half Sinusoid)
Anti-Vibration	10grms, 10~1000Hz
