    AKG392 MEMS Digital Accelerometer Three Axis Vibration Sensor For Bridge Monitoring

    Ask Lasest Price
    Brand Name : RION
    Model Number : AKG392-485
    Certification : CE, ISO
    Price : $260.00/Pieces
    Payment Terms : T/T,PAYPAL
    Supply Ability : 3000 PCS/MONTH
    Delivery Time : 7 days for samples
    • Product Details
    • Company Profile

    AKG392 MEMS Digital Accelerometer Three Axis Vibration Sensor For Bridge Monitoring

    RION AKG392 MEMS Digital Accelerometer Three axis Vibration Sensor for Bridge Monitoring



    ▶ MAIN FEATURE

    ★ Three axes (X, Y, Z)

    ★ Output signal: RS232; RS485; TTL

    ★ Power supply voltage: 9~36V

    ★ Size: L34.3×W34.3×H38.5mm

    ★ Working temperature: -40°C ~ +85°C

    ★ Storage temperature: -40°C ~ +85°C

    ★Excellent deviation stability, good environmental performance (shock, vibration and temperature)


    ▶ APPLICATION

    ★ Medical equipment

    ★ Bridge

    ★ Large machinery, engines

    ★ Automobile

    ★ Road roller

    ★ Crash records, fatigue monitoring and prediction

    ★ Wind power generation

    ★ Low-frequency vibration and automatic monitoring

    ★ Traffic system monitoring, roadbed analysis and high-speed railway

    fault detection


    Specifications


    AKG392PARAMETERSUNIT
    Range±2±4±8±10±20±40g
    Bias calibration<1<1<1<1<1<1mg
    Measure axisX,Y,ZX,Y,ZX,Y,ZX,Y,ZX,Y,ZX,Y,Zaxis
    Power on/off repeatability<2<2<2<2<2<2mg(max)

    Bias temperature

    coefficient

    0.150.150.150.750.750.75%/℃(typical)

    Resolution/threshold

    (@ 1Hz)

    < 1< 1< 1< 1< 1< 1mg(max)
    Non-linearity<0.5<0.8<1<1<1<1% FS(max)
    Bandwidth (3DB)500500500500500500Hz
    Cross axis sensitivity111222%

    Transverse vibration sensitivity ratio

    112555%
    Density of noise21212186.686.686.6μg/√Hz
    Resonance frequency2.42.42.45.55.55.5kHz
    Output rate5Hz,10Hz,25Hz,50Hz,100Hz,200Hz,500Hz,1000Hz
    Output InterfaceRS232/RS485/TTL
    ProtocolRION 68 protocol and MODBUS RTU protocol
    Input(VDD_VSS)9~36 VDC
    Operating current consumption<60mA @ 12 VDC
    ConnectorIndustry standard M12 connector
    WeightProduct net weight: 82g, Magnetic base: 48g, L-shaped adapter plate 20g
    Size

    Product size: 34.3*34.3*38.5mm

    Magnetic adsorption base size: 34.23*34.23*6mm

    L-shaped adapter plate size: 36*44*15mm


    ▶ COMMUNICATION PROTOCOL

    The product includes 68 protocol and MODBUS RTU two protocols. The default configuration parameters of the protocol are as follows:

    PROTOCOLRION 68 PROTOCOLMODBUS-RTU
    Address code01
    Broadcast address2550
    Serial port baud rate96009600
    Parity bitNo parityEven parity
    Serial port start bit1 bit1 bit
    Serial port data length8 bits8 bits
    Serial port stop bit1 bit1 bit
    Output modeQuestion and answerQuestion and answer
    Data FormatData formatData format
    Data check methodChecksumCRC16

    RION 68 protocol and MODBUS protocol mutual switching method:

    Open the serial port debugging assistant, select the baud rate 115200, no parity, stop bit 1, the connection port number, make the host computer send hexadecimal 0xAA regularly for every 10ms. Power on the product and reply "RION" or "MRTU" to indicate that the change to the corresponding protocol is successful. After the switch is successful, the parameters are all the above default parameters.




    Size
