    DMI420 Protection Digital Inclinometer With Night Vision Fours Colors Display

    Ask Lasest Price
    Brand Name : RION
    Model Number : DMI410,DMI420
    Certification : CE
    Price : $234.00/Pieces
    Payment Terms : T/T, Paypal
    Supply Ability : 3000/month
    Delivery Time : 5 days for sample
    • Product Details
    • Company Profile

    DMI420 Protection Digital Inclinometer With Night Vision Fours Colors Display

    Cheap Low Cost Digital Inclinometer with Night Vision Fours Colors Display, IP54 Protection & 100g High Anti-impact


    Key Features

    ★ Auto-angle interleaved compensation function

    ★ Auto temperature drift compensation
    ★ User can calibrate by himself

    ★ Built-in recharge industry battaries
    ★ Night vision fours colors screen

    ★ IP54 protection class
    ★ °/mm Dual units switch function

    ★ 100g High anti-impact

    Application

    ★ Building construction

    ★ Automobile four-wheel testing

    ★ Road slope

    ★ Machinery installation
    ★ Piping installation
    ★ Industrial platform
    ★ Turntable testing
    ★ Cloud deck angle detection
    ★ Production ji
    PARAMETERSDMI420 Protection Digital Inclinometer With Night Vision Fours Colors DisplayDMI410 DMI420
    Measurement axisSingle axisDual axis
    Angle measurement range±180 °±90 °
    Angle measurement accuracy0.05 °(full range)0.05 °(full range)
    Angle measure resolution0.01°0.01°
    mm/m measure range±999.9mm/m±999.9mm/m
    mm/m measurement accuracy0.9mm/m(full range)0.9mm/m(full range)
    mm/m measurement resolution0.1mm/m0.1mm/m
    LCD visible area sizeL40*W32mm
    Working temperature-10℃~ +70℃
    Working humidity85%RH
    Power supply3.7V Charging Lithium battery
    Ideal charging time3h
    Battery continuous working time8h(±0.5)
    Data output signalStandard 5Pin USB connector
    Anti-vibration10g@11ms,3 Axial Direction (Half Sinusoid)
    Impact resistance10grms,10~100Hz
    Waterproof levelIP54
    MaterialMetal aluminum
    SizeL83*W19*H53mm
    Weight≤140g


    ON/OFF: Press for 2seconds to power on or off ;
    HOLD: This key to lock the current data, convenient customer records;
    ZERO: This button can switch in the absolute and relative measurement mode;(screen display ABS means absolute status, display REL means relative measurement)
    HOLD & ZERO: Press HOLD button until the screen appear a small lock sign then press ZERO, can switch in “Angle” and “mm/m” two units of measurement;
    ON/OFF&HOLD: Press ON/OFF button until the screen to be black then press the HOLD button , can calibrate the accuracy according to the screen;
    ON/OFF&ZERO: Press ON/OFF button until the screen to be black then press the HOLD button , can calibrate the ZERO according to the screen;
    RESET HOLE: If the instrument occur a crash in working, key can't operation, can use the needlepoint hard object to insert into the hole for touch the button;
    USB JACK: For charging purposes or Angle of external connection, data transmission;
    WARNING LIGHT: Charging warning lights, lights up means is charging, light off mens has been filled with power then can take off the charger .( In order to keep the battery with a long life please don't use it as much as possible when it is charging with power.)


    FAQ
    Q: How to choose suitable products before ordering? A: According to your application, select the measurement axis , the appropriate measuring range, the main parameters of the output, or not sure, please contact us as soon as possible, our staff will be the first time to get in touch with you and provide the best solution and the most preferential price. Q: What's kind of payment methods ? A: We support T/T and Paypal methods, you can choose any one, after payment, please inform us in time, so that we can arrange your order and deliver the goods as soon as possible. Q: How about lead time for order ? A: After we receive your payment, the samples will be sent in 3-7 working days. If mass order please confirm the delivery schedule with our sales staff in advance so as to avoid unnecessary delay. Q: How about quality inspection before shipment ? We have several testing departments will be in strict accordance with the requirements of inspection of goods quality and functions, to ensure the quality of each with 100% qualified product, and the products will be inspected /tested again to ensure no any problem before shipment . Q: What's the transportation methods ? A: You can arrange courier to pick up goods from our company, or provide your international express account number to pay for your local courier after goods reach to your hands, but also can delivery by DHL, FEDEX, UPS, TNT, EMS... Etc through our shipping forwarder . Q: How about after-sale service ? A: Please check the package status in time after receipt of the goods as soon as possible, and product performance test, if any quality problem please contact us first, we will deal with your problems and feedback as soon as possible. Q: How about product warranty and repair service? A: Warranty for one year, In general, we can provide the repaired service in free charge if non damaged within one year , and individual cases can be extended to 3 years or more. If over a certain warranty period or damage caused by user , we will charge a rea
